• Rugged design
• Full rated to ANSI 150 or higher by request
• Any flange drilling
• Standard 316 Stainless Steel construction
• Any weldable material
• MSS SP81 face to face
• Metal Seat to MSS SP81 leak rates
• Resilient Seat drip tight
• Tool Steel deflection cones
• Ceramic lined inlet cones
• Dry powder Service option

• Reverse flow option
• Pressurised Bonnets
• Gate covers
• Spindle boots
• Pneumatic cylinders
• Hydraulic cylinders
• Hydraulic Hand pumps
• Stainless steel handwheels
• Proximity switches
• Positioners
• Lockouts

Order Codes

Example : 100, D, AMK, N, T, C4, G-U-SP

Valve Size

Bore 50mm to larger

Flange Drilling

D = AS2129 Table D

C = AS2129 Table C

E = AS2129 Table E

A = ANSI 150

R = DIN 10

X = Non Standard (Specify)

T = Add for through drilling

Body Type

AMK = Australian Manufactured Knife Gate Valve, 316 Stainless Steel Body & Gate

Seat

M = Metal Seat integral with body

N = Nitrile

V = Viton

E = EPDM

P = PTFE

Packing

T = Standard wet service: Cross plait Ramie yarn PTFE lubricated , max 250° C

TD = Dry powder service: Diagonally braided graphite with reinforced carbon corners. Max 400° C

X = Non Standard (Specify)

Actuation

H = Handwheel

C# = Double acting pneumatic cylinder. # Represents bore size in inches

B/S = No actuator

X = Non Standard (Specify)

Options

X = Special (specify)
